Fiber Collimator unit

Characteristic

This is a Collator unit for use the measurement such as a loss of materials.
We put AR coat on fiber end lens side and realize transmission loss less than 1dB.
We also produce automatic robot for Collator unit manufacturing.

Specification

Application wavelength (µ)	0.63 0.8 1.3 1.55

Use fiber	Single mode (SM) Multi mode (MM) polarization maintenance fiber (P)

Collator diameter	0.3~2ø
Loss	1dB>
Connector	FC,SC

Example

Type turn

FCU-	155-	SM
	(Wavelength)	(Fiber)
